Quick Details

  • Place of Origin: Sichuan, China (Mainland)
  • Brand Name: Jiexiang
  • Model Number: JX-16AM
  • Output Frequency: 47-860MHz
  • Output level: ≥40dBmV(100dBμV)
  • A/V Ratio: -11 to -18 dB (Adjustable)
  • C/N Ratio: Digital TV Head-end System
  • Video input: 1.0Vp-p @87.5% Modulation
  • Audio input: 0.775Vp-p

Packaging & Delivery

Packaging Details Standard carton filled with foam, 1 pcs/ctn
Delivery Time Shipped in 2-5 Workdays after payment

Secure Payment service support !! We are Trade Assurance supplier!


Economical Headend 16AM Analog Modular

















































Specifications

Frequency Range

 47~860MHz (Any one channel)

Output Level

 ≥105dBμV

Output Level Adjustment Range

 0~-20dB (Variable)

Video to Audio Carrier

 -10dB~-30dB adjustable

Output Impedance

 75Ω

Spurious Output Suppression

 ≥60dB

Frequency Accuracy

 ≤±5KHz (VHF) ,  ≤±10KHz (UHF)

Video Output Reflection

 ≥12dB (VHF)  ≥10dB (UHF)

Video Input Level

 1.0Vp-p (87.5% Modulation)

Video Input Impedance

 75Ω

Differential Gain

 ≤5% (87.5% Modulation)

Differential Phase

 ≤5°(87.5% Modulation)

C/L Delay

 ≤45 ns

Flatness

 ±1dB

Video Modulator Depth

 0~90% (Variable)

Video S/N

 ≥55dB

Audio Input Level

 1Vp-p (±50KHz)

Audio Input Impedance

 600Ω

Audio S/N

 ≥57dB

Audio Pre-weighted

 50μs

Power Supply

 AC 220V±10% 50Hz±2Hz,50W

Working Temperature

0~40°C

Dimensions

19 Inch 4 U housing



 picture of catv modulator



Beside this model,we also have 24 in 1 CATV analog modulator,16 in 1 agile modulator for you refer.
