Quick Details

  • Place of Origin: Sichuan, China (Mainland)
  • Brand Name: Jiexiang
  • Model Number: JX8765
  • Product name: dvb-t encoder modulator
  • Application: Digital TV Head-end System
  • MOQ: 1 set for dvb-t encoder modulator
  • Input: CVBS/YPbPr/HD/SDI optional
  • Output: RF Output
  • Management: Web-based NMS
  • Modulation: DVB-S/DVB-S2
  • Audio encoding: MPEG-1 Layer 2, MPEG4-ACC
  • Keywors: dvb-t encoder modulator
  • Power supply: AC 100V~240V

Packaging & Delivery

Packaging Details Standard carton box + Assembly manual for dvb-t encoder modulator
Delivery Time Deliver within three working days

In-stock work effectively lowest cost per channel dvb-t encoder modulator

Technical Indicators



Dual  SDI Encoding Input
Video
EncodingH.264
InputSDI*2
Resolution1920*1080_60P, 1920*1080_50P, 1920*1080_60i, 1920*1080_50i
720*480_60i, 720*576_50i
Audio
encodingMPEG1 Layer II
Sample rate48KHz
Bit rate64kbps, 96kbps, 128kbps, 192kbps, 256kbps, 320kbps
DVB-S/S2 Modulation Section
DVB-S QPSK: FEC 1/2,2/3,3/4,5/6,7/8
DVB-S2 QPSK:FEC 1/2,3/5,2/3,3/4,4/5,5/6,8/9,9/10
DVB-S2 8PSK FEC 3/5,2/3,3/4,5/6,8/9,9/10
RF output : 950.00-2150.00 MHz, 10Khz step;
IF: 50-200MHz
Symbol rate: 0.05-20.0Msps
Roll Off: 0.35, 0.25, 0.2
Output level: -10db~-41.5db
GeneralSystemLocal interfaceLCD + control buttons
Remote managementWeb NMS
Stream Out2 ASI out (BNC type);
IP (MPTS/SPTS) out (100M)
NMS interfaceRJ45, 100M
LanguageEnglish
Physical SpecificationPower supplyAC 100V~240V
Dimensions482*300*44mm
Weight4.5 kg
Operation temperature0~45℃

Welcome to inquiry for more details!

Advantages

       1.MPEG2 SD/HD and MPEG4 SD/HD Encoding Module optional

       2.Support DVB-S/S2 RF (IF Optional) output and ASI output

       3.LCN support (Logical Channel Number)

       4.Output Frequency: 950-2150MHz; IF: 50-200MHz

       5.Support BISS fucntion

       6.Support 10MHz reference clock

 7.Support Web NMS and front panel LCD & Keyboard control
