8*DVB-S2 IRD Scrambler & Transmodulator(8RF+ASI IN,QAM RF out) DVB-S2

FOB Reference Price:Get Latest Price
US $200-1,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Sichuan, China (Mainland)
Brand Name:
Jiexiang
Model Number:
JX-8565D
QAM Channel:
4
input:
8 tuner input
Output Channel:
4 RF output
Maximum simulcrypt CA:
4
Output Attenuation:
-25dBm~-6dBm(each carrier), 0.5dB Stepping
Application:
8*DVB-S2 IRD Scrambler & Transmodulator
NMS:
support
Constellation:
16,32,64,128,256QAM
RF Range:
48~960MHz,1kHz stepping
Weight:
4kg
Supply Ability
Supply Ability:
2000 Set/Sets per Month
Packaging & Delivery
Packaging Details
standard export paper carton and foam,1 set/ctn.
Port
main port in China

8*DVB-S2 IRD Scrambler & Transmodulator



                                                                                               ------Best service for you



Product Description

Outline

QAM Transmodulator with Scrambler is a high performance and cost-effective ASI mux-scrambling QAM modulating device latest designed by our Company, Which provide 16 ASI input interface. After 4 channels multiplexing, scrambling and QAM modulating process, then it gives 4 RF output (4 adjacent frequencies by 1 RF port). The device is characterized with high integrated level, high performance and low cost. This is very adapting to newly generation CATV broadcasting system

Features

  • Support 16 ASI input, 4 ASI input optional
  • Fully support EN300 429/ITU-T J.83A/B/C
  • Fully support DVB general scrambling system description ETR289, simulcrypt standard ETSI 101 197 and ETSI 103 197
  • Support 4 channels multiplexing, 4 channels scrambling and 4 channels QAM modulating
  • Simultaneously support 4 simulcrypt CA
  • Symbol rate adjusting range: 5.0Msps~7.0Msps
  • Five constellation modes: 16QAM, 32QAM, 64QAM, 128QAM, 256QAM
  • Support PCR accurate adjusting
  • Support PSI/SI editing and inserting
  • Excellent RF output performance index, MER≥40db
  • Support LCD display and keyboard
  • Support NMS operation

Specifications

Input

16 channels ASI input, BNC interface

Multiplexing

Input Channel

16 channels ASI input or 4 ASI input option1



8 channels tuner input     option2

Output Channel

4 RF output

Maximum PID Remapping

256 per input channel

Function

PID remapping(automatically or manually)

PCR accurate adjusting

Generate PSI/SI table Automatically

Scrambling

Maximum simulcrypt CA

4

Standard

ETSI 101 197, ETSI 103 197

Connection

Local/remote connection

Modulation

QAM Channel

4

Standard

EN300 429/ITU-T J.83A/B/C

Symbol Rate

5.0~7.0Msps,1ksps stepping

Constellation

16,32,64,128,256QAM

FEC

RS(204, 188)

RF Output

Connector

F Type, 75Ω impedance

RF Range

48~960MHz,1kHz stepping

Output Attenuation

-25dBm~-6dBm(each carrier), 0.5dB Stepping

MER

>=40db

ACLR(Adjacent channel leakage ratio)

-60dBC

System

Support LCD display, keyboard operation, and NMS operation. English and Chinese operation interface conversion

Support Software Upgrading through Ethernet

General

Dimension(W*D*H)

482mm×455mm×44.5mm

Weight

4kg

Temperature

0~45°C(Operation) ; -20~80°C(Storage)

Power

AC100V±1050/60HzorAC 220V±10%,50/60HZ

Consumption

25W


Our Services



About us



Chengdu Jiexiang Technology Co. Ltd



Digital TV Headend System Manufacturer



         Website:www.cdjxdvb.cn



 About the shippment



within 5 working days for sample order/1-3 weeks for bulk order



Our service:



 1.Reply your enquire within 24 hours.



 2.Professional technology team to make Digital systemdiagram for your project.



 3.Professional after-sales team to solve your issues when faced.



Glance to our company:

1. Fifteen years professional DVB experience



2.Rice experience of Digital TV headend project.



3.OEM&ODM for large order quantity





4.Widely application situation,such as Bars,College,Hospital,Monitoring system and so on.



5.Excellent quality,Fastest deliverly time,Best service.

4IN1 QAM to QAM Transmodulator  Principle Chat



NDS3343-16 Principle Chart

 Photo of  4IN1 QAM to QAM Transmodulator  8 turner 4 in 1 Mux-Scrambling QAM Modulator.jpg


Company Information

Project case:



system on the way


FAQ




Packaging & Shipping
